| Mfr Part | Datasheet | Series | Manufacturer | Package | Topology | Product Status | Mounting Type | Switching Frequency | Function | Input Voltage | Output Voltage | Number of Outputs | Operating Temperature | Output Type | Output Current |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ADR441ARZ |  |
ADR441 | Analog Devices | SOIC-8 | N/A | Active | Surface Mount | N/A | Precision Voltage Reference | 7 V – 36 V | 2.5 V | 1 | −40°C to +85°C | Reference | N/A |
ADR441ARZ
Devices
Logic Cells: Precision voltage reference IC
Logic Slices: Low-noise, low-drift reference circuitry
Embedded RAM (eRAM): –
Package: SOIC-8
Operating Temperature: -40 °C to +125 °C
Specifications
Part Number Definition
ADR441 is a high precision, low drift XFET bandgap voltage reference with fixed 2.5 V output voltage. ARZ represents 8-lead narrow body SOIC surface mount package, delivered in tube packaging for prototype debugging and small batch equipment assembly.
Core Electrical Performance Parameters
This ultra-stable voltage reference is designed for high-resolution data acquisition systems, precision calibration instruments and low-noise analog circuits. It generates a fixed 2.500 V accurate output voltage with outstanding long-term stability and minimal temperature fluctuation deviation.
The input supply voltage ranges from 2.8 V up to 18 V, compatible with most common single analog power rails in industrial measurement devices. Typical temperature coefficient is less than 3 ppm/°C across the whole operating temperature range, which maintains consistent reference voltage output during ambient temperature changes.
It features extremely low broadband noise, which prevents noise degradation of conversion accuracy for 16-bit to 24-bit ADC and DAC chips. Excellent line regulation and load regulation characteristics effectively resist disturbances caused by power supply voltage variation and load current fluctuation.
The chip can both source and sink small load currents without the requirement of additional buffer amplifiers in most low-current application scenarios. Internal thermal hysteresis suppression structure improves output repeatability after repeated temperature cycling. Quiescent supply current is kept low to reduce overall system static power consumption.
Packaging and Assembly Specifications
Packaged in standard 8-pin narrow SOIC plastic surface mount housing with small footprint, saving PCB layout space for miniaturized analog front-end modules. Moisture Sensitivity Level is MSL3; all reflow soldering operations shall be finished within 168 hours after opening the original vacuum sealed package. Tube packaging is applied to support manual circuit testing and small-volume trial production conveniently.
Environmental and Compliance Standards
Industrial operating temperature range spans -40 °C to +125 °C, supporting reliable long-term operation in industrial process control instruments, portable precision test equipment, medical analytical devices and laboratory calibration systems under harsh temperature conditions. Produced with lead-free manufacturing technology, the component complies with global RoHS environmental directives. Simple peripheral circuit configuration reduces the usage of auxiliary passive components and simplifies high-precision analog circuit layout work.
Typical Application Fields
Precision voltage reference source for high bit resolution ADC and DAC converters
Calibration benchmark for handheld multimeters and bench laboratory measuring instruments
Analog power reference for industrial weighing, pressure and temperature transmitters
Battery-powered portable data logger and IoT sensor acquisition modules
Medical diagnostic equipment low-noise analog signal conditioning circuits
