- Includes ST state-of-the-art patented technology
- 코어: Arm® 32비트 Cortex®-M4 CPU with FPU, Adaptive real-time accelerator (ART Accelerator) allowing 0-wait state execution from flash memory, frequency up to 168 MHz, memory protection unit, 210 DMIPS/1.25 DMIPS/MHz (Dhrystone 2.1), and DSP instructions
- 추억
- Up to 1 Mbyte of flash memory
- Up to 192+4 Kbytes of SRAM including 64-Kbyte of CCM (core coupled memory) data RAM
- 512 bytes of OTP memory
- Flexible static memory controller supporting CompactFlash™, SRAM, PSRAM, NOR and NAND memories
- LCD 병렬 인터페이스, 8080/6800 모드
- Clock, reset, and supply management
- 1.8 V to 3.6 V application supply and I/Os
- POR, PDR, PVD 및 BOR
- 4-to-26 MHz crystal oscillator
- 내장형 16 MHz 공장 보정 RC(1% 정확도)
- 보정 기능이 있는 RTC용 32 kHz 발진기
- 보정 기능이 포함된 내장형 32kHz RC
- Low-power operation
- Sleep, Stop, and Standby modes
- VBAT supply for RTC, 20×32-bit backup registers + optional 4 KB backup SRAM
- 3×12-bit, 2.4 MSPS A/D converters: up to 24 channels and 7.2 MSPS in triple interleaved mode
- 2×12-bit D/A converters
- 범용 DMA: FIFO 및 버스트 전송을 지원하는 16-스트림 DMA 컨트롤러
- Up to 17 timers: up to twelve 16-bit and two 32-bit timers up to 168 MHz, each with up to 4 IC/OC/PWM or pulse counter and quadrature (incremental) encoder input
- 디버그 모드
- Serial wire debug (SWD) & JTAG interfaces
- Cortex-M4 Embedded Trace Macrocell™
- Up to 140 I/O ports with interrupt capability
- Up to 136 fast I/Os up to 84 MHz
- Up to 138 5 V-tolerant I/Os
- Up to 15 communication interfaces
- Up to 3 × I2C 인터페이스 (SMBus/PMBus)
- Up to 4 USARTs/2 UARTs (10.5 Mbit/s, ISO 7816 interface, LIN, IrDA, modem control)
- Up to 3 SPIs (42 Mbits/s), 2 with muxed full-duplex I2S to achieve audio class accuracy via internal audio PLL or external clock
- 2 × CAN interfaces (2.0B Active)
- SDIO 인터페이스
- 고급 연결 기능
- 온칩 PHY를 탑재한 USB 2.0 풀 스피드 디바이스/호스트/OTG 컨트롤러
- 전용 DMA, 온칩 풀스피드 PHY 및 ULPI를 탑재한 USB 2.0 고속/풀스피드 디바이스/호스트/OTG 컨트롤러
- 10/100 Ethernet MAC with dedicated DMA: supports IEEE 1588v2 hardware, MII/RMII
- 최대 54MB/s의 8~14비트 병렬 카메라 인터페이스
- True random number generator
- CRC 계산 유닛
- 96비트 고유 ID
- RTC: 1초 미만의 정확도, 하드웨어 캘린더
- All packages are ECOPACK2 compliant
|
